Sale!
Lewmar Size 03 Low Profile #39903030 Direct From Factory
Home / Hatches / Lewmar Size 03 Low Profile #39903030 Direct From Factory

Lewmar Size 03 Low Profile #39903030 Direct From Factory

Original price was: $352.86.Current price is: $141.14.

For orders under $60.00, a shipping fee of $9.99 applies.

SKU: SK0090349 Category: Tag:
Share

Lewmar 39903030 Hatches

The Low Profile hatches have soft styling and sleek looks. They are ideal for use on power craft. Smaller ventilation hatches are suitable for any deck location on sailboats and the larger hatches can even be used as foredeck hatches. The hatch also features Lewmar’s unique sealing system allowing easy acrylic replacement

All sizes suitable for CE Area 2 (Deck, Coachroof, Cockpit and Transom).

Mounting Instructions
Fit to a flat surface with a maximum tolerance of +/- 1mm. Fastening size at hinge section use (M6 / 1/4″). Fastening size for lower frame use 5mm CSK screw No.10 UNC 2 BA.

Specifications
Support System Lower Frame (in) Acrylic Colour Hatch Weight (lb) Acrylic Window Thickness (in)
Self Supporting 9/16 Smoke Gray 3.5 5/16
Dimensions
Length X (in) Width Y (in) Height Z (in) Radii R (in) Cut-Out Length X1 (in) Cut-Out Width Y1 (in) Cut-Out Radii R1 (in)
9 11/16 11 7/8 1 2 7/8 6 15/16 9 1/8 1 11/16

Hatch Type: Low Profile

Normalized SKU: 39903030
UPC Code: 743683107023
